Introduction and Methodology

Equipment

All measurements are made using a miniDSP E.A.R.S. binaural microphone jig: https://www.minidsp.com/products/acoustic-measurement/ears-headphone-jig

Source: audio-GD NFB11.28 TXCO (almost always in High Gain)

About the E.A.R.S.

Fundamentally it is a binaural microphone/headphone stand with simulated silicone ear-lobe mounts.

While the miniDSP E.A.R.S. is a flawed tool, a measurement graph on its own is practically useless. Here I am offering something different - a massive catalogue of graphs for comparison made by the same user with the same equipment and the same methodology. While there will always be imperfections, this is by far the best use-case for such a device.

It is the most simple all-in-one measuring tool available.

PROS	CONS
Cheap all-in-one solution	Not the highest quality materials and parts
Works well with free REW software	Silicone ears are too stiff resulting in poor seal of on-ear headphones. Human ears and skin are more flexible
Height adjustable headband mount	Silicone ears have 4 protruding screw-heads resulting in poor seal of some over-ear headphones
USB - plug and play microphone functionality	No angle adjustment of the ears which can lead to a poor seal with some headphones
Consistent results for large over-ear headphones	No simulated ear-canal
	Inconsistent dip artefact in graphs at 4KHz. Most prominent with closed-back headphones.
	Some headphones require rubber bands around to apply more pressure to create a seal
	No width adjustment. It is a very narrow head-size, like a child's head, which can cause a bad seal with some headphones

Down to 10Hz!!!

All my graphs go down to 10Hz, and I fervently believe all headphone graphs should too.

In all my years of listening, modding, pad rolling, measuring etc, one thing has stuck out as being more significant than anyone else has ever made it out to be - the headphone's ability to reproduce sub-bass.

Sub-bass performance is key in producing a greater sense of dynamics and scale, and headphones that can't do it cannot compete with headphones that can. These are frequencies that your ears can feel, and many people can audibly hear below 20Hz. The 20-20KHz rule is a myth. Personally my hearing goes down to 8Hz (and up to 16KHz) so sub-bass performance is extremely important to me. I also notice that many planars have excellent linear response that goes down to 10hz. But there are also some that are only linear down to 20Hz, and they cannot convey the same sense of scale, texture and depth as their superiors. I almost find it too 'convenient' that companies are also only publishing graphs down to 20Hz, as this allows them to show off a much more linear graph than the truth.

Room EQ Wizard

All graphs are made using REW: https://www.roomeqwizard.com/

Frequency Response Graphs - Disclaimers

All my graphs use the same scale.

All graphs use the 'Headphone Calibration' compensation files provided by miniDSP unique to my E.A.R.S. jig. All IEM and earbud graphs use the 'IEM Calibration' file.

The frequency response scale goes from 10-20,000Hz. I do this for 3 reasons.

• Firstly, to make these graphs somewhat comparable to other measurements online created by other miniDSP E.A.R.S. owners/users.

• Secondly, to make these graphs somewhat comparable to Tyll's graphs on innerfidelity.

• Thirdly, there are too many online graphs that start at 20Hz. Many companies love to show perfectly linear bass "down to 20Hz".... but there is so much information and character of a headphone you can learn from seeing the lowest sub-bass performance of a headphone between 10-20Hz. Headphones that have a strong sub-bass down to 10Hz more often present music with grander 'scale' and dynamics. There are many headphones that start rolling-off strongly before 20Hz which is often why there is little regard given to these frequencies, but my experiences with hundreds of headphones taught me how important it really is.

While the dB scale remains the same for all graphs, the relative position or 'height' of one graph to another should not be taken as meaning anything, and as such should be completely ignored.

IEM and Earbud graphs are very inaccurate because the miniDSP E.A.R.S. jig is simply not designed to measure these properly. I have tried to measure them as accurately as possible using as consistent a method as I can, however none of them should be fully trusted.
